Our Recent Concrete Scanning/ Utility Locates Projects:
Concrete Scanning at St. Mary’s Hospital, Camrose, AB
We recently completed concrete mapping project at St. Mary’s Hospital in Camrose, AB. This is a proposed location for a new patient bed to be bolted into the concrete floor. The slab was confirmed to be reinforced with Qdeck and wiremesh. Scantec also detected power conduits in the slab. Scantec recommended the client to drill in to the trough areas of the decking only and avoid the anomalous objects in the slab.
How to scan a thick concrete slab_Concrete Scanning in Calgary, AB
How to accurately scan and transfer core location for a 24-inch thick slab? Many times we have been asked:”What is the maximum depth you can scan a slab?”. The answer is: It depends!.
We have all the necessary tools to maximum the penetration depth. For general concrete scanning purposes such as cutting and coring, probably 900 MHz is the lowest frequency we use which designed up to 3ft (1m) of penetration. More common, 2000 MHz and 1600 MHz GPR antennas are used to “see” down to around 1ft.
Ground Penetrating Radar (GPR) Concrete Scanning in Calgary
Scantec GPR Services has been scanning thousands of slabs in Calgary to help clients determining the type of slabs, thickness, reinforcement information and location of critical objects embedded within the slabs prior to doing any cutting or coring through.
This week we have completed a scanning project for a general contractor at a busy shopping centre during a store renovation. It was on a waffle slab with varied beam sizes and rebar on the top slab. It is noted that there was no access to the slab bottom as there were other active stores on the below level and the ceiling was completely covered.
Environmental Drilling Utility Clearance in Calgary, AB
We have recently completed this interior scanning at a big fabrication facility in Calgary. The client was an environmental consulting firm drilling both interior and exterior soil boring holes through concrete slab-on-grade. For the interior holes, we would need to identify buried electrical, sewer, water, gas, hydraulic line trenches/features if present within the proposed borehole locations.
They were also trying to drill near a former underground storage tank (UST), so we were able to see the backfill material there as well, which would help us position their boreholes. Reinforcement within the concrete slab on grade was the issue with traditional EM utility locates as the signals would be spreading out. Our typical approach was using a high-resolution GPR antenna to scan the slab itself to clear any conduits and piping within the concrete sprior to performing deeper soil investigation with lower frequency antennas which would provide
Scantec Private Utility Locating in Calgary, Alberta
Scantec GPR Services Inc. provides private underground utility locating services in Calgary with experienced GPR professionals. SCANTEC can accurately locate almost everything underground from cables to pipes and all utilities either conductive lines or fiber optic cables. Our surveys help client save time and money while maintaining high level of safety on site by avoiding any damage to sub-surface critical objects or structures.
We utilize state of the art GPR equipment to perform any task. We also provide concrete scanning to clients in Calgary to map out rebar, post-tensioned cables, electrical conduits and voids. We are also able to tell all information about the slab such as thickness, depth of bars, size of rebar and spacing etc. We always carry multiple GPR antennas on our truck for every job site to make sure we can investigate different depth ranges if we need to. Thus, when it comes to sub-surface detection, either the objects are within the concrete slab or buried underneath the slab, we can find them all.
SCANTEC Private Utility Locating in Edmonton, Alberta
Scantec GPR Services Inc. provides private underground utility locating services in Edmonton with experienced GPR professionals. SCANTEC can accurately locate almost everything underground from cables to pipes and all utilities either conductive lines or fiber optic cables. Our surveys help client save time and money while maintaining high level of safety on site by avoiding any damage to sub-surface critical objects or structures.
Concrete Scanning in downtown Calgary, AB
Scanning structural and slab-on-grade in Calgary area.
